Brand Name: Nakamura Dental
Product Name: ND Air Motor Handpiece 2 Hole
Product Type: Dental Air Motor
Connection Type: 2 Hole / Borden Type
Speed at 0.2 MPa: 20,000 RPM
Rotation Speed Range: 500–25,000 RPM
Rotation Direction: Forward / Reverse
Rotation Torque: 160 g·cm
Maximum Air Pressure: 50 psi
Maximum Air Consumption: 60 L/min
Coupling with Handpiece: ISO Standard E-Type
Connection with Hose: ISO Standard A-Type, 2 Holes
Sterilization: Autoclave at 135°C for 20 Minutes
Professional Use: Dental Clinics and Practices
Product Description
- ND Air Motor Handpiece 2 Hole by Nakamura Dental is a pneumatic dental motor designed to power compatible low-speed straight and contra-angle handpieces.
- The motor provides a variable operating range of 500–25,000 RPM, allowing dental professionals to select an appropriate speed for different clinical procedures.
- Its forward/reverse rotation function provides greater versatility for procedures requiring changes in rotational direction.
- The motor features an ISO Standard E-Type handpiece coupling, enabling use with compatible E-Type dental attachments.
- A 2-hole Borden Type connection provides compatibility with suitable dental unit air hoses.
- With a specified rotation torque of 160 g·cm, the motor provides dependable rotary performance for routine low-speed dental applications.
- The unit can be autoclaved at 135°C for 20 minutes, supporting proper instrument processing between patients.
- Suitable for dentists looking for a versatile 2-hole dental air motor for everyday clinical use.
Features
- Professional dental air motor handpiece designed for low-speed dental procedures.
- Adjustable rotation speed ranging from 500 to 25,000 RPM.
- Provides approximately 20,000 RPM at 0.2 MPa operating pressure.
- Forward and reverse rotation provides flexibility for different clinical applications.
- Delivers a rotation torque of 160 g·cm for reliable performance.
- Features an ISO Standard A-Type 2-hole (Borden Type) hose connection.
- ISO Standard E-Type coupling allows connection with compatible straight and contra-angle handpieces.
- Maximum air consumption of 60 L/min.
- Designed to operate at a maximum air pressure of 50 psi.
- Autoclavable at 135°C for 20 minutes for routine infection control.
- Suitable for repeated professional use in dental clinics and practices.
- Operating compatible low-speed dental handpieces.
- Restorative dental procedures.
- Finishing and polishing with suitable attachments.
- Prophylaxis procedures with compatible instruments.
- Dental laboratory and chairside adjustments where appropriate.
- Driving compatible contra-angle handpieces.
- Driving compatible straight handpieces.
- General low-speed rotary dental procedures.
- Variable 500–25,000 RPM speed range provides flexibility for different procedures.
- Forward and reverse rotation increases clinical versatility.
- E-Type coupling provides compatibility with suitable dental handpiece attachments.
- 2-hole Borden connection works with compatible dental unit hoses.
- Pneumatic operation provides dependable low-speed rotary performance.
- 160 g·cm torque supports controlled clinical operation.
- Autoclavable construction supports routine infection-control requirements.
- Compact and practical design for everyday professional dental use.
Material & Care
- Clean the air motor thoroughly after every clinical use according to the manufacturer's instructions.
- Lubricate using an appropriate dental air motor lubricant when recommended.
- Autoclave at 135°C for 20 minutes as specified.
- Allow the motor to dry completely after sterilization before storage.
- Inspect the E-Type coupling and 2-hole connection regularly.
- Ensure correct air pressure before operating the motor.
- Do not exceed the specified 50 psi maximum air pressure.
- Connect only to compatible ISO E-Type handpieces and ISO A-Type 2-hole hoses.
- Store in a clean and dry environment when not in use.
